JOB HANDLING CAPACITY

Max Size of component handled: 450mm X 650mm X 110mm
Lightest weight of components casted: 15 grams (0.033 lbs)
Heaviest weight of components casted: 45 kilograms (99.20 lbs)

Minimum of wall thickness casted:

1.70mm for stainless steel
2.25mm for low alloys/mild & carbon steel
1.30 mm for aluminum alloy

Volumetric requirement for parts: From 10 Pieces to 10,000+ Pieces

We do support low volume for most of ferrous and non-ferrous alloy casting

COMMONLY POURED ALLOYS: TYPES OF MATERIALS

Castings produced in most engineering materials include low and high steels, stainless steels, tool steels, nickel based alloys, cobalt based alloys, and copper based alloys.

Low Alloy Steel: 1020, 1045, 1050, 1095, 4130, 4140, 4150, 4340, 6150, 8620, 8650
Martensitic Stainless Steel: 410, 416, 420, 431, 15-5PH, 17-4PH, 440A, 440C, CA-6NM
Austenitic Stainless Steel: 303, 304, 304L, 316, 316L, 316/NonMag, CF-8M, CF-3M, 330, 347, 20-CB3, Alloy 20, CN-7M, CF10-SMnM
Duplex Stainless Steel: ASTM A890 Grade 4A
Copper Base Alloys: CDA872, CDA875, CDA876, CDA903, CDA905, CDA954
Tool Steels: A2, A6, D2, D5, L6, M2, M52, O1,  S5, S7
Aluminum: A356 T6
Ferritic Stainless Steel: 409, 430, 436, 446
Nickel Base Alloys: NI-B, NI-C, NI-x, NI-625, Monel E, Non-Galling SS
Cobalt Base Alloys: CoAlloy3, CoAlloy6
